What Are the Three Special Markings on a Folding Ruler?

A folding ruler is a very common measuring tool in our daily lives, used by carpenters, electricians, construction workers, and other professions. However, many people may just treat it as an ordinary ruler, overlooking the special markings hidden within. These markings aren't just randomly printed; they represent different functions. Understanding their meaning can help you work more efficiently.

Understanding the Special Markings on a Folding Ruler

Typically, a standard wooden or plastic folding ruler will have three special symbols printed on it. These symbols are usually red or black and are located in different locations on the ruler.

1. Red Arrow Marking

You may see a red arrow mark on a section of a folding ruler. This arrow usually points to 7.1 cm (or 2.8 inches). The practical purpose of this mark is to help us quickly locate the center of screw holes. In carpentry or furniture installation, this distance is a common measurement for screw hole center-to-center distance. This mark eliminates the need for repeated measurements and allows you to drill directly to the mark, greatly improving work efficiency.

2. Red Circle Marking

On the other side of a folding ruler, you may find a red circle, usually located at the 30.5 cm (or 1 foot) mark. This mark is used to measure standard brick or tile sizes. In the construction industry, many materials are manufactured in inches. This mark helps workers quickly check whether material lengths meet standards, ensuring project accuracy.

3. Black or Red Diamond Marking

One of the most common markings on a folding ruler is a black diamond, usually located at the 45 cm (or 17.7 inches) mark. This mark is used to measure the angle of a miter line. When making miter joints or cuts, this mark helps you quickly find the 45-degree miter line. This is very useful for creating miter joints on picture frames, furniture, and other applications, ensuring a tight and aesthetically pleasing joint.

Why Are These Markings Important to Know?

Knowing these special markings on a folding ruler is more than just a little knowledge. More importantly, they can help you:

• Improve Your Work Efficiency: Instead of repeatedly calculating and measuring, you can simply use the markings to complete specific tasks.


• Ensure Accurate Measurements: These markings are expertly designed to ensure accurate measurements in specific scenarios.


• Expand Your Tool's Usage: These markings transform a simple folding ruler into a more complex measurement solution.



Next time you use a folding ruler, take note of these small markings. They're a clever addition to your measuring tool's design, making your work easier and more professional.
